Vibrating Table
Vibrating Table
Electromagnetic vibrating table consist of solid base plate and a vibrating top. The top platform vibrates at 3000 vibrations per minute through an electromagnet housed inside. Each table is supplied with a control panel, which supplies pulsating current to electromagnet and also controls the amplitude of vibration. Control panel operates on 230 V.A.C. single phase.
Used for packing of products. Testing of welding joints. Eliminating vords in moulded parts. Achieving uniformity in ceramic moulded parts.
Application
Vibrating table is very useful in several industries
A. For testing of welded joints in automobilie industry.
B. For testing of delicate joints in electronic industry.
C. For effective packing of fluffy and difficult to handle powder in chemical and pharmacuetical industry.
D. For proper flow of powder in dies and moulds to get perfect moulded parts.
Capacity
Vibrating tables are manufactured in different sizes and load conditions as under…
|
Table Size in mm. |
Power Consumption |
Maximum Loading |
|
300X300 |
200 watts |
25 Kgs. |
|
450X450 |
350 watts |
50 Kgs. |
|
600X600 |
600 watts |
100 Kgs. |
|
750X750 |
900 watts |
200 Kgs. |
|
900X900 |
1200 watts |
300 Kgs. |
