Rectangular Vibro Screen
Rectangular Vibro Screen
‘SAIDEEP’ Rectangular vibrating screens offer a highly efficient approach to screening. This single development has resulted in tremendous advantages as far as reduced maintenance, compactness and simplicity are concerned. Besides the simplicity of the drive, many other features have been incorporated to provide a machine which is specifically designed for heavy duty applications, long life, and low operating and maintenance costs, at a competitive price. The standard range of screens is presented later in the brochure, and these are normally available on short delivery.
Operation
‘SAIDEEP’ Rectangular Vibrating Screens are equipped with two vibrating motors rotating in opposite directions. This dual motor configuration causes the screens frame to vibrate in a linear or straight-line motion perpendicular to the plane of the motors. This results in excellent forward conveyance of oversized particles , even when the screens frame is in an uphill position. Depending upon the application, the Rectangular screens frame can be position at various degrees downhill. Maximum capacity is achieved in the uphill position, causing the formation of a pool at the feed end of the machine. The head or pressure from the pool increase fluid throughout. The horizontal vibrating screens of the screens frame efficiently conveys the oversized particles out of the pool area where they are then discharged.
Flexibility
The rectangular vibrating screens can be adapted by the factory to meet special requirements regarding plant layout, rectangular screens performance and environmental constraints. Specify your particular requirements, or enquire about the range of features, accessories, painting systems and materials of construction currently available.
Applications
- Iron ore jiggling process
- Upgrading the Iron ore
- Iron ore washing plant
- Silica Sand washing plant
- Mineral washing plant
- Mining washing plant
- Trash Screens/Gold Recovery
- Iron ore beneficiation plant
- Hematite ore beneficiation plant
- Hematite jiggling plant
- Magnetite beneficiation plant
- Magnetite jiggling plant
- Garnet sand processing unit
- Garnet sand washy unit
- Breweries
- Carbon Column Safety Screens
- Clay (Grit Removal)
- Digester Clean-up
- Fish and Seafood
- Fruit and Vegetable Processors
- Hog Waste (B.O.D. Reduction)
- Industrial Wastewater
- Meat Packaging Plants
- Municipal Waste
- Paper Fiber Recovery
- Petro-Chem Industry
- River Dredging
- Tanneries
- Textiles
- Fruit and Vegetable Processors
- Hog Waste (B.O.D. Reduction)
- Industrial Wastewater
- Meat Packaging Plants
Key Benefits
- High fluid capacity.
- Ideal for dilute slurries and/or low amounts of oversize such as scalping or trash screens applications.
- Appropriate for the removal of grit or other contaminants from viscous slurries.
- Screens openings can range from 3/8inch (10mm) to 400 mesh (38 microns).
- Low headroom requirements.
- Uniform straight-line conveying action.
- High open area polyurethane screens surfaces or various woven wire designs minimize or eliminate screens blinding.
